MIL-DTL-14824C(AR)
Conformance Inspection by classification of characteristics
DRAWING NUMBER
PARAGRAPH
TITLE
10535926
4.3.2.4
Body Assembly
SHEET 2 OF 2
NEXT HIGHER
ASSEMBLY
10535925
INSPECTION
CLASSIFICA
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
PARAGRAPH
METHOD
TION
CRITERIA
REFERENCE
Minor
201
Diameter of rotating band groove
Level II
3.2.4
AIE
202
Length from rotating band groove to
Level II
3.2.4
AIE
start of angle
203
Length of rotating band flat
Level
II
3.2.4
AIE
204
Length total max
Level
II
3.2.4
AIE
205
Angle at front of rotating band
Level
II
3.2.4
AIE
206
Angle at rear of rotating band relief
Level
II
3.2.4
AIE
groove
207
Width of rotating band
Level II
3.2.4
AIE
208
Width of rotating band groove
Level II
3.2.4
AIE
209
Depth of undercut front and rear of
Level II
3.2.4
Visual
rotating band (if applicable)
210
Width of undercut front and rear of
Level II
3.2.4
Visual
rotating band (if applicable)
211
Foreign matter in cavity
Level II
3.2.4
Visual
212
Evidence of poor workmanship
Level II
3.9
Visual
19
