MIL-DTL-70507A (AR)
Drawing
Slide lock for fuze.
number
4.3.2.3
13016773
Next higher
assembly
Conformance
Requirement
Classification
Examination or test
criteria
paragraph
Inspection
method
reference
Critical
None defined
Major
101
Thickness prior to
Level IV
3.3
AIE
forming
Level IV
3.3
AIE
102
Slot profile 2 places
prior to forming
103
Outside profile prior
Level IV
3.3
AIE
to forming
104
Angle of slide lock
Level IV
3.3
AIE
prior to forming
105
Inside radius
Level IV
3.3
AIE
106
Distance to bottom of
Level IV
3.3
AIE
slide lock
107
Radius of slide lock
Level IV
3.3
AIE
tab (2 places)
108
Radius of slotted tab
Level IV
3.3
AIE
(2 places)
109
Total width
Level IV
3.3
AIE
110
Distance across tabs
Level IV
3.3
AIE
at bottom
111
Distance to outside of
Level IV
3.3
AIE
slide lock
112
Distance to end of
Level IV
3.3
AIE
slide lock
Minor
201
Evidence of poor
Level II
3.8
Visual
workmanship
11
