MIL-DTL-70507A (AR)
Drawing number
4.3.2.9
Charge bag assembly (required for new production only.
12934962
Next higher
assembly
Conformance
Requirement
12934963
Classification
Examination or test
criteria
paragraph
Inspection method
reference
Critical
None defined
Major
101
Length of bag
Level IV
3.3
AIE
102
Distance to end of heat
Level IV
3.3
AIE
seal max.
103
Distance to side heat seal
Level IV
3.3
AIE
104
Minimum width of both
Level IV
3.3
AIE
heat seals over entire
length
105
Heat seals incomplete (2
Level IV
3.3
Visual
places)
106
Strength of bag charge
1/
3.3
4.4.3
assembly heat seal
107
Location of end stitching
Level IV
3.3
AIE
108
Distance to side stitching
Level IV
3.3
AIE
109
Location of eyelet
Level IV
3.3
AIE
Minor
201
Stitching incomplete (2
Level II
3.3
Visual
places)
202
Fold width eyelet end
Level II
3.3
AIE
203
Fold misalignment over
Level II
3.3
AIE
max.
204
Thickness of assembled
Level II
3.3
AIE
eyelet
205
Evidence of poor
Level II
3.8
Visual
workmanship
NOTES:
1/ Sample 20 per lot, accept on 0, reject on 1 failure.
