MIL-DTL-70507A (AR)
Drawing number
4.3.2.4
Grenade assembly (prior to loading into projectile).
13001904,
13001906
Next higher
assembly
Conformance
Requirement
13001907
Classification
Examination or test
criteria
paragraph
Inspection method
reference
Critical
1
Slide protruding excessively
3.3
AAIE
100%, Level VII,
from fuze indicating armed or
3/
partially armed condition
2
Slider lock feature missing or 100%, Level VII
3.3
AAIE
not seated at correct height
3
Trigger missing or out of
3.3
AAIE
100%, Level VII,
position
3/
4
Safety pin missing
3.3
AAIE
100%, Level VII
5
Safety clip missing
100%, Level VII,
3.3
AAIE
2/
Major
101
Tape loop incorrectly
Level IV
3.3
Visual
contained by slide lock.
102
Arming screw clinch missing,
Level IV
3.3
Visual
incomplete, or not properly
centered
103
Tape loop/washers missing or
100%
3.3
Visual
incorrect
104
Fuze housing cracked or
Level IV
3.3
Visual
deformed
105
Stud clinch missing
Level IV
3.3
Visual
106
Depth of recapped stud
Level IV
3.3
AIE
107
Unthreading torque test of
1/
3.3
4.4.15.2
clinched arming screw
108
Arming test of fuze slide
1/
3.3
4.4.15.3
109
Tape loop pull test
1/
3.3
4.4.15.4
110
Pull test of clinched studs
1/
3.3
4.4.15.5
111
Tape loop missing or incorrect
Level IV
3.3
Visual
NOTES:
1/ Two samples per 1800 grenade assemblies produced on each machine. Accept on 0, reject on 1failure.
2/ Safety clip shall be removed immediately prior to grenade assembly insertion into projectile.
3/ Examination shall be performed prior to slide lock being fitted onto fuze grenade assembly.
