MIL-DTL-60377C (AR)
Conformance inspection by classification of characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
SHEET 1 OF 3
4.3.2.2
Projectile loading assembly (Before post cycle
9216352 or
heating)
13010426
(Radiographic acceptance requirements)
NEXT HIGHER
ASSEMBLY
CLASSIFICAT
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
ION
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Critical
1
Base separation in excess of that
Note 1,2
3.5.3
4.5.1
permitted (see 6.16.1)
2
Cavities, other than piping, cracks
Note 1,2
3.5.5
4.5.1
or annular rings in Segment A with a
total area in excess of 1/16 square
inch or length in excess of 1/4 inch
(see 6.16.2)
3
Annular rings in Segment A or B with
Note 1,2
3.5.8
4.5.1
a width in excess of 1/32 inch
(see 6.16.3)
4
Piping cavities in Segment A
Note 1,2
3.5.6
4.5.1
exceeding 1/16 square inch in total
area or 1/8 inch in width
(see 6.16.4)
5
Cracks in Segment A in excess of the
Note 1,2
3.5.7.1
4.5.1
requirements of Table I (see 6.16.5)
Note 1. 100% inspection by level II or better certified reader with a 1 in 10 review by a
Level III certified non destructive test inspector.
Note 2. Any projectile that has any of the critical defects listed above shall be classed
defective and removed from the lot.
17
