MIL-DTL-60377C (AR)
3.2.3 Projectile loading assembly (prior to assembly of
liner). The components and assemblies shall comply with all
requirements specified on drawing (dwg) 9216352 or 13010426.
3.2.4 Projectile, 155MM, HE, M107 LAP (prior to assembly
of supplementary charge, if applicable). The components and
assemblies shall comply with all requirements specified on
drawing (dwg) 9216352 or 13010426.
3.2.5 Projectile 155MM, HE, M107 LAP (prior to assembly
of lifting plug). The components and assemblies shall comply
with all requirements specified on drawing (dwg) 9216352 or
13010426
3.2.6 Projectile, 155MM, HE, M107 Loading Assembly and
Marking Diagram. The components and assemblies shall comply
with all requirements specified on drawing (dwg) 9216352 or
13010426.
3.2.7 Packing and marking for 155MM projectile (metal
pallet). The components and assemblies shall comply with all
requirements specified on drawing (dwg) 9216352 or 13010426.
3.2.8 Packing and Marking for Pallet, Ammunition, for
Projectile 155MM (alternate wood pallet). The components and
assemblies shall comply with all requirements specified on
drawing (dwg) 9216352 or 13010426.
3.3 Ammunition lot numbering. Ammunition lot numbers
shall be assigned in accordance with MIL-STD-1168.
3.4 Loading of high explosive
3.4.1 Interior cavity metal defects. The body cavity
shall be free of scale, fins, burrs, draw marks, laminations,
embedded foreign matter, folds, pits and sharp edges, in
accordance with visual standards (see 6.3).
3.4.2 Unsolidified pool of paint. There shall be no
unsolidified pool of paint or blister in the projectile cavity
prior to loading of the explosive. The interior surface of the
projectile shall be dry when the high explosive is poured into
the projectile.
3.4.3 Projectile cavity contamination. The interior
cavity of the projectile prior to loading shall be free from
foreign matter, chemical residue, oil and grease.
3.4.4 Interior coating. Projectile having the interior
wall imperfectly coated, in accordance with visual standards
(see 6.3) shall not be loaded.
4
