MIL-DTL-60377C (AR)
Conformance inspection by classification of characteristics
DRAWING NUMBER
PARAGRAPH
TITLE
SHEET 3 OF 3
9216352 or
4.3.2.2
Projectile loading assembly (Before post
13010426
cycle heating)
(Radiographic acceptance requirements)
NEXT HIGHER
ASSEMBLY
CLASSIFICATI
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
ON
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Major
101
Cast defects in Segments A (except
Note 1,2
3.5.4
4.5.1
cracks,) B, C or D in excess of the
through
requirements of table 1
3.5.8
102
Porous areas in excess of that
Note 1,2
3.5.4
4.5.1
permitted
103
Cracks in Segment A in excess of
Note 1,2
3.5.7.2
4.5.1
that permitted
104
Rotating band gaps in excess of that
Note 1,2
3.5.1
4.5.1
permitted
Minor
201
Cracks in Segments A, B and C
Note 1,2
3.5.7.2
4.5.1
combined in excess of that permitted
Note 1. 100% inspection by Level II or better certified reader with a 1 in 10 review by a
Level III certified non destructive test inspector.
Note 2. Any projectile that has any of the defects listed above shall be classed
defective and removed from the lot.
