MIL-DTL-60377C (AR)
Conformance inspection by classification of characteristics
DRAWING NUMBER
PARAGRAPH
TITLE
SHEET 2 OF 3
9216352 or
4.3.2.2
Projectile loading assembly (Before post
13010426
cycle heating)
(Radiographic acceptance requirements)
NEXT HIGHER
ASSEMBLY
CLASSIFICATI
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
ON
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Critical
6
Cast defects in Segment B in excess
Note 1,2
3.5.4
4.5.1
of twice the requirements of Table I
through
(see 6.16.6)
3.5.8
7
Metal parts defects, except rotating
Note 1,2
3.5.1
4.5.1
band gaps, in excess of that
permitted (see 6.11 and 6.16.7)
8
Foreign material in the explosive
Note 1,2
3.5.2
4.5.1
cast (see 6.16.8)
Note 1. 100% inspection by Level II or better certified reader with a 1 in 10 review by a
Level III certified non destructive test inspector.
Note 2. Any projectile that has any of the defects listed above shall be classed
defective and removed from the lot.
18
