MIL-DTL-60584B (AR)
Conformance inspection by classification of characteristic
PARAGRAPH
TITLE
DRAWING NUMBER
4.3.3.1
Adapter.
10542948
SHEET 1 OF 3
NEXT HIGHER ASSEMBLY
10542946
CLASSIFICATION
CONFORMANCE
EXAMINATION OR TEST
REQUIREMENT
INSPECTION METHOD
CRITERIA
PARAGRAPH
REFERENCE
Critical
1
Diameter of press fit area
100%
3.2.1
AIE
Major
101
Pitch diameter of external thread
Level IV
3.2.1
AIE
102
Major diameter of external thread, min.
Level IV
3.2.1
AIE
103
Length from rear face to basic
Level IV
3.2.1
AIE
diameter on rear taper
104
Runout of forward taper to outside
Level IV
3.2.1
AIE
thread pitch diameter and shoulder
105
Runout of projected pitch diameter of
Level IV
3.2.1
AIE
internal threads (2 places) to out- side thread pitch diameter,
forward face and shoulder (see Note 1)
106
Runout of press fit diameter at rear
Level IV
3.2.1
AIE
of fuze cavity to external thread pitch diameter and shoulder
107
True position of diameter at rear of
Level IV
3.2.1
AIE
fuze cavity to press fit diameter
108
Pitch diameter of internal thread
Level IV
3.2.1
AIE
109
Minor diameter of internal thread, max.
Level IV
3.2.1
AIE
Note 1. These inspections are not required when components are to be supplied as assemblies.
11
