MIL-DTL-60584B (AR)
Conformance inspection by classification of characteristic
DRAWING NUMBER
PARAGRAPH
TITLE
10542947
4.3.3.3
Body
SHEET 3 OF 4
Cont.
NEXT HIGHER ASSEMBLY
10542946
CLASSIFICATION
REQUIREMENT
EXAMINATION OR TEST
INSPECTION METHOD
CONFORMANCE
PARAGRAPH
REFERENCE
CRITERIA
123
Outside diameter of body (2 places)
Level IV
3.2.3
AIE
at rear of rotating band undercut
and blend area
124
Runout of rear face with body
Level IV
3.2.3
AIE
125
Runout of boattail with body
Level IV
3.2.3
AIE
126
Runout of ogive with body
Level IV
3.2.3
AIE
127
Runout of projected pitch diameter of
Level IV
3.2.3
AIE
threads (2 places) with body and
forward face
128
Runout of bourrelet with body
Level IV
3.2.3
AIE
129
Diameter of bourrelet, min
Level IV
3.2.3
AIE
130
Mechanical properties
4.4.1
3.2.3
4.4.1
131
Foreign matter on band seat
Level IV
3.5.1, 3.5.6
Visual
132
Scoring or knurling missing from
Level IV
3.2.3
Visual
rotating band seat
133
Weight (excluding lifting plug
Level IV
3.2.4
AIE
and grommet)
17
