MIL-DTL-60584B (AR)
Conformance inspection by classification of characteristic
DRAWING NUMBER
PARAGRAPH
TITLE
10542947
4.3.3.3
Body
SHEET 2 OF 4
Cont.
NEXT HIGHER ASSEMBLY
10542946
CLASSIFICATION
REQUIREMENT
EXAMINATION OR TEST
INSPECTION METHOD
CONFORMANCE
PARAGRAPH
REFERENCE
CRITERIA
Major
110
True position of base counter bore
Level IV
3.2.3
AIE
with pitch diameter and forward face
111
Length from front of boattail to rear
Level IV
3.2.3
AIE
of rotating band seat
112
Location of rotating band seat
Level IV
3.2.3
AIE
113
Thickness of wall, min. at blend area
Level IV
3.2.3
AIE
114
Variation in wall thickness to rear
Level IV
3.2.3
AIE
of bourrelet
115
Variation in wall thickness forward
Level IV
3.2.3
AIE
of bourrelet
116
Width of rotating band seat
Level IV
3.2.3
AIE
117
Length, total
Level IV
3.2.3
AIE
118
Length from front face to rear of
Level IV
3.2.3
AIE
bourrelet
119
Diameter of base counter bore
Level IV
3.2.3
AIE
120
Distance from bottom of base
Level IV
3.2.3
AIE
counter bore to basic diameter on
taper of counter bore
121
Diameter of nose counter bore
Level IV
3.2.3
AIE
122
Diameter of rear face
Level IV
3.2.3
AIE
16
