MIL-DTL-60584B (AR)
Conformance inspection by classification of characteristic
DRAWING NUMBER
PARAGRAPH
TITLE
10542947
4.3.3.3
Body
SHEET 1 OF 4
NEXT HIGHER ASSEMBLY
10542946
CLASSIFICATION
REQUIREMENT
EXAMINATION OR TEST
CONFORMANCE
INSPECTION METHOD
PARAGRAPH
CRITERIA
REFERENCE
Critical
1
Non-destructive test for metal defective
100%
3.4.1
4.4.4 - 4.4.4.2
Major
101
Pitch diameter
Level IV
3.2.3
AIE
102
Minor diameter, max.
Level IV
3.2.3
AIE
103
Diameter of rotating band seat
Level IV
3.2.3
AIE
104
Effective thread length
Level IV
3.2.3
AIE
105
Depth from front face to bottom of
Level IV
3.2.3
AIE
base counterbore
106
Length from front face to first
Level IV
3.2.3
AIE
basic diameter
107
Length from front face to second
Level IV
3.2.3
AIE
basic diameter
108
Length from bottom of base counterbore
Level IV
3.2.3
AIE
to first inside diameter
109
Length from bottom of base counterbore
Level IV
3.2.3
AIE
to second inside diameter
15
