MIL-DTL-60584B (AR)
Conformance inspection by classification of characteristic
DRAWING NUMBER
PARAGRAPH
TITLE
10542948
4.3.3.1
Adapter
SHEET 2 OF 3
Cont.
NEXT HIGHER ASSEMBLY
10542946
CLASSIFICATION
REQUIREMENT
EXAMINATION OR TEST
CONFORMANCE
INSPECTION METHOD
PARAGRAPH
CRITERIA
REFERENCE
Major
110
Depth to bottom of fuze cavity
Level IV
3.2.1
AIE
111
Depth to bottom of counterbore at
Level IV
3.2.1
AIE
rear of fuze cavity
112
Effective internal thread length, min
Level IV
3.2.1
AIE
113
Diameter of counterbore at rear of
Level IV
3.2.1
AIE
fuze cavity
114
Length from front face to first
Level IV
3.2.1
AIE
basic diameter on taper
115
Length from front face to second basic
Level IV
3.2.1
AIE
diameter on taper
116
Metal defective
Level IV
3.4
Visual
117
Reverse taper in press fit area
Level IV
3.2.1
AIE
118
Surface finish of press fit area(note 2)
Level IV
3.2.1
Visual/Comparison
blocks
119
Radius at start of press fit area improper, or incorrect form
Level IV
3.2.1
AIE/Visual
or not present for entire circumference
Note 2. Surface finish of press fit area shall not be inspected until all manufacturing and
gaging operations have been completed.
12
