MIL-DTL-60584 Projectile,155 Millimeter - Smoke, Wp, Metal Parts Assembly, M110A2This specification covers the manufacturing and assembly of the Projectile, 155MM, Smoke, WP, M110A2 Metal Parts.\(See 6.1\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20


MIL-DTL-60584B (AR)
Conformance inspection by classification of characteristic
PARAGRAPH
TITLE
DRAWING NUMBER
4.3.3.3
Body
10542947
SHEET 4 OF 4
Cont.
NEXT HIGHER ASSEMBLY
10542946
CLASSIFICATION
REQUIREMENT
INSPECTION METHOD
EXAMINATION OR TEST
CONFORMANCE
PARAGRAPH
REFERENCE
CRITERIA
Minor
201
Depth of nose thread counter bore
Level II
3.2.3
AIE
202
Radii or chamfers missing or incorrect
Level II
3.2.3
Visual
203
Surface finish improper
Level II
3.8.2
Visual
204
Evidence of shot or sand blasting on
Level II
3.2.3
Visual
rotating band seat
205
Burr
Level II
3.8.4
Visual
206
Foreign matter (except as otherwise
Level II
3.8.5
Visual
classified)
207
Metal defective
Level II
3.4
Visual standards
208
Evidence of poor workmanship
Level II
3.8
Visual
