MIL-DTL-60585 Case, Projectile, Burster, Assembly, M1E1This specification covers the requirements, examinations and tests for the metal parts of the Case, Projectile Burster - Assembly, M1E1.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20


'Microsoft Word - DTL10542950 _Final_ 05-30-06 _Transformation to MIL spec_.ƒ' by neil.stern - Page 10 of 20
MIL-DTL-60585B (AR)
Conformance inspection by classification of characteristic
PARAGRAPH
TITLE
DRAWING NUMBER
4.3.2.2
Sleeve (Alternative Two Piece Design)
10542949
SHEET 1 OF 1
NEXT HIGHER ASSEMBLY
10542950
CLASSIFICATION
EXAMINATION OR TEST
REQUIREMEN
INSPECTION METHOD
CONFORMAN
T PARAGRAPH
REFERENCE
CE CRITERIA
Critical
None defined
Major
101
Diameter of counterbore rear of sleeve
Level IV
3.2.2
AIE
102
Diameter at rear of sleeve (outside)
Level IV
3.2.2
AIE
103
Length total
Level IV
3.2.2
AIE
104
Diameter of through hole max
Level IV
3.2.2
AIE
Minor
201
Length from rear of flange to bottom
Level II
3.2.2
AIE
of counterbore rear of sleeve
202
Radii or chamfers missing or incorrect
Level II
3.2.2
Visual
203
Surface finish improper
Level II
3.2.2
Visual
204
Burr
Level II
3.6
Visual
205
Foreign matter
Level II
3.7
Visual
206
Evidence of poor workmanship
Level II
3.7
Visual
207
Metal defective
Level II
3.5
Visual
10
