MIL-DTL-60585B (AR)
Conformance inspection by classification of characteristic
DRAWING NUMBER
PARAGRAPH
TITLE
10542950
4.3.2.6
Case, projectile, burster assembly
SHEET 1 OF 2
(prior to coating)
NEXT HIGHER ASSEMBLY
9217031
CLASSIFICATION
EXAMINATION OR TEST
REQUIREMEN
INSPECTION METHOD
CONFORMAN
CE CRITERIA
T PARAGRAPH
REFERENCE
Critical
1
Air pressure test
100%
3.2.6
4.3.3.5
2
Hydrostatic test (if applicable)
100%
3.2.6
4.3.3.2
Major
101
Flange not functionally concentric with
Level IV
3.2.6
AIE
press fit surface
102
True position of rear of case for given length to press fit
Level IV
3.2.6
AIE
surface and rear of
Flange
103
Perpendicularity of front face of flange with press fit
Level IV
3.2.6
AIE
surface
104
Location of reinforcing sleeve
Level IV
3.2.6
AIE
105
Improper cleaning
Level IV
3.4.1
Visual
106
Burster case not clean prior to testing
100%
3.4.2
Visual
15
