MIL-DTL-60585B (AR)
Conformance inspection by classification of characteristic
PARAGRAPH
TITLE
DRAWING NUMBER
4.3.2.3
Casing (Alternative Two Piece Design)
10542949
SHEET 1 OF 1
NEXT HIGHER ASSEMBLY
10542950
CLASSIFICATION
EXAMINATION OR TEST
CONFORMAN
REQUIREME
INSPECTION METHOD
CE CRITERIA
NT
REFERENCE
PARAGRAPH
Critical
None defined
Major
101
Diameter at front of tube (outside)
Level IV
3.2.3
AIE
for minimum indicated length
102
Outside diameter at rear of transition zone
Level IV
3.2.3
AIE
105
Thickness of wall minimum for minimum
Level IV
3.2.3
AIE
Length
106
Thickness of wall rear of transition
Level IV
3.2.3
AIE
Zone
Minor
201
Radii or chamfers missing or incorrect
Level II
3.2.3
Visual
202
Surface finish improper
Level II
3.2.3
Visual
203
Burr
Level II
3.6
Visual
204
Foreign matter
Level II
3.7
Visual
205
Evidence of poor workmanship
Level II
3.7
Visual
206
Metal defective
Level II
3.5
Visual
11
