MIL-DTL-60585 Case, Projectile, Burster, Assembly, M1E1This specification covers the requirements, examinations and tests for the metal parts of the Case, Projectile Burster - Assembly, M1E1.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20


'Microsoft Word - DTL10542950 _Final_ 05-30-06 _Transformation to MIL spec_.ƒ' by neil.stern - Page 16 of 20
MIL-DTL-60585B (AR)
Conformance inspection by classification of characteristic
PARAGRAPH
TITLE
DRAWING NUMBER
4.3.2.6
Case, projectile, burster assembly
10542950
SHEET 2 OF 2
Con't
(prior to coating)
NEXT HIGHER ASSEMBLY
9217031
CLASSIFICATION
EXAMINATION OR TEST
REQUIREMEN
INSPECTION METHOD
CONFORMAN
CE CRITERIA
T
REFERENCE
PARAGRAPH
Major
107
Joint Section Test
4.3.3.3
3.3.1
4.3.3.3
108
Tension Test
4.3.3.4
3.2.6
4.3.3.4
Minor
201
Surface finish improper (except as
Level II
3.2.6
Visual
otherwise classified)
202
Reinforcing tube not properly brazed to
Level II
3.2.6
Visual
Body
203
Marking missing, incorrect or illegible
Level II
3.2.6
Visual
204
Burr
Level II
3.6
Visual
205
Foreign matter
Level II
3.7
Visual
206
Evidence of poor workmanship
Level II
3.7
Visual
207
Braze metal not visible for full 360
Level II
3.3
Visual
degrees at exterior juncture of casing
and rear of sleeve (if applicable)
208
Braze metal not visible for full 360
Level II
3.3
Visual
degrees at exterior juncture of casing
and plug (if applicable)
