MIL-DTL-60585 Case, Projectile, Burster, Assembly, M1E1This specification covers the requirements, examinations and tests for the metal parts of the Case, Projectile Burster - Assembly, M1E1.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20


'Microsoft Word - DTL10542950 _Final_ 05-30-06 _Transformation to MIL spec_.ƒ' by neil.stern - Page 9 of 20
MIL-DTL-60585B (AR)
Conformance inspection by classification of characteristic
PARAGRAPH
TITLE
DRAWING NUMBER
4.3.2.1
Tube, reinforcing
10535949
SHEET 1 OF 1
NEXT HIGHER ASSEMBLY
10542950
CLASSIFICATION
EXAMINATION OR TEST
CONFORMANC
REQUIREME
INSPECTION METHOD
E CRITERIA
NT
REFERENCE
PARAGRAPH
Critical
None defined
Major
101
Inside diameter
Level IV
3.2.1
AIE
102
Thickness of wall
Level IV
3.2.1
AIE
103
Metal defective
Level IV
3.5
AIE
Minor
201
Minimum flat of wall front and rear
Level II
3.2.1
AIE
202
Length total
Level II
3.2.1
AIE
203
Width of slot
Level II
3.2.1
AIE
204
Radii or chamfers missing or incorrect
Level II
3.2.1
Visual
205
Surface finish, improper
Level II
3.2.1
Visual
206
Burr
Level II
3.6
Visual
207
Foreign matter
Level II
3.7
Visual
9
