MIL-DTL-60585B (AR)
Conformance inspection by classification of characteristic
PARAGRAPH
TITLE
DRAWING NUMBER
4.3.2.7
Case, projectile, burster assembly
10542950
SHEET 1 OF 1
NEXT HIGHER ASSEMBLY
9217031
CLASSIFICATION
REQUIREMEN
INSPECTION METHOD
EXAMINATION OR TEST
CONFORMAN
T PARAGRAPH
REFERENCE
CE CRITERIA
Critical
None defined
Major
101
Pitch diameter of thread
Level IV
3.2.7
AIE
102
Minor diameter of thread, max.
Level IV
3.2.7
AIE
103
Diameter over reinforcing tube
Level IV
3.2.7
AIE
104
Length of effective thread, min.
Level IV
3.2.7
AIE
105
Length of thread cavity, max.
Level IV
3.2.7
AIE
106
Protective coating incomplete or damaged
Level IV
3.2.7
Visual
107
Cavity fails to accept full length of plug gage
100%
3.2.7
Visual
AIE
108
Corrosion preventive compound missing
Level IV
3.2.7
Visual
from press fit surface
109
Air Pressure test stamp missing
100%
3.2.7
Visual
110
Hydrostatic test stamp missing (if applicable), see Note 1
100%
3.2.7
Visual
Minor
None defined
Note 1. Any part found without the required test stamp shall be tested to determine if the part fails critical test. If the part fails the critical test it
shall be treated as a Critical Nonconformance. If the part passes the critical test, it shall be treated as a Major Nonconformance.
